The Woodward 115475 083813A.202, also cataloged as the 115475 Industrial Control Module, operates as a dedicated hardware component for high-speed signal processing and serial/Ethernet communication within Woodward industrial control platforms.

Hardware Specifications

Thermal Heat Sink Dissipation Profiles and Communication Execution

The Woodward 115475 083813A.202 incorporates dedicated thermal heat sink dissipation profiles across its internal power regulation circuitry to maintain stable operation up to +70 deg C. Dual Ethernet channels alongside RS232 and RS485 serial ports support high-bandwidth telemetry and real-time command transfer. The hardware manages internal loop processing while ensuring heat generated by continuous 24 VDC / 10 W execution is efficiently transferred to the module enclosure, preventing thermal throttling during sustained industrial automation control tasks.

Frequently Asked Questions

Q: What is the nominal input voltage and power draw for the Woodward 115475 083813A.202?

A: The module requires a regulated 24 VDC auxiliary power supply and has a maximum power consumption rating of 10 W.

Q: What serial and network interfaces are available on the module?

A: The unit features two Ethernet ports, one RS232 serial port, and one RS485 serial port for industrial network integration.

Q: What are the primary physical dimensions and weight of this control unit?

A: The hardware measures 273.6 mm x 214.1 mm x 59.2 mm and weighs 1.5 kg.

Field Installation Guidelines

• Mount the module securely using specified mounting points inside a shielded metal enclosure to comply with industrial noise immunity standards.
• Ensure adequate clear space surrounding the chassis to facilitate passive heat dissipation via the integrated heat sink paths.
• Connect incoming 24 VDC power lines using appropriate wire gauges, observing correct polarity prior to system startup.
• Terminate all RS485 serial loops with standard matching resistors and ground Ethernet cable shielding to prevent signal degradation.
