The General Electric Multilin 269PLUS-100P-120 is a specialized motor management relay designed for the protection, control, and monitoring of AC motors. This unit provides comprehensive protection features to ensure motor longevity and operational safety in demanding industrial environments.

Features

• Designed for 100 Ohm Platinum RTD input sensors.
• Supports 120 V AC / 125 V DC control voltage configurations.
• Equipped with 4 relay connections for flexible output control.
• Integrated protection logic with a maximum current rating of 2 Amps.
• Robust construction with an operating temperature range of -25 degC to +60 degC.
• Reliable operation in high-humidity environments up to 95% non-condensing.

Technical Specifications

Installation Guidelines

• Ensure the device is powered down before performing any wiring or installation.
• Mount the relay in a clean, dry, and vibration-free environment to prevent premature component failure.
• Use appropriate shielded cabling for RTD inputs to minimize electromagnetic interference (EMI).
• Verify that the control voltage matches the specifications on the device label before energizing.
• Maintain adequate clearance around the unit to ensure proper ventilation and heat dissipation.
• Follow standard industrial grounding practices to protect the relay from transient surges.

FAQ

What is the primary function of the 269PLUS-100P-120? This relay is engineered to provide motor management, including thermal protection and monitoring using RTD inputs for critical industrial motor applications.

Does this unit support DC control voltage? Yes, this specific model is rated for 120 V AC or 125 V DC control voltage.
