Description

The ABB Bailey INLIM03 is a specialized Loop Interface Module designed for integration within the Infi 90 distributed control system. This module facilitates reliable communication and data exchange between system loops, ensuring consistent performance in demanding industrial process control environments. It is engineered to handle signal processing and synchronization tasks required for maintaining loop integrity.

Features

• Supports high-speed data rates of up to 1 Mbps.
• Integrated memory architecture featuring 2 kbytes RAM and 4 kbytes ROM for LIM, and 32 kbytes RAM and 16 kbytes ROM for BIM.
• Optical isolation rated at 500V to protect sensitive control circuitry from electrical noise and surges.
• Designed for robust operation within a temperature range of 0 degC to +60 degC.
• Compatible with standard Infi 90 system configurations.

Technical Specifications

Installation Guidelines

• Ensure the control system is powered down before inserting or removing the INLIM03 module from the rack.
• Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to internal components.
• Verify that the module is fully seated in its designated slot to ensure proper backplane connection.
• Maintain adequate ventilation within the cabinet to keep ambient temperatures within the specified operating limits.
• Route signal cables away from high-voltage lines and sources of electromagnetic interference (EMI) to maintain data integrity.

FAQ

What are the common spare part numbers for this module?

The INLIM03 is often cross-referenced with spare models including PINLIM03, INLIM03R, and YINLIM03.

What is the primary function of the INLIM03?

The INLIM03 serves as a Loop Interface Module within the Bailey Infi 90 system, managing data communication and synchronization between loops.
