The ABB PS700 1JNL100175-851 is a high-performance Mach 3 Distributed I/O unit designed for demanding industrial automation environments. This module provides a robust interface for both digital and analog signal processing, ensuring reliable data acquisition and control within distributed architectures.

Features

• Integrated support for PROFINET IO and Modbus TCP protocols.
• High-speed data communication at 100Mbps (full duplex).
• Synchronized cycle times of 1ms or less with minimal jitter.
• High-resolution 16-bit analog signal processing.
• Galvanic isolation rated at 1500V AC for enhanced system protection.

Technical Specifications

Installation Guidelines

• Ensure the module is mounted in a clean, dry environment with adequate ventilation to maintain operating temperatures within the specified range.
• Always disconnect power before installing or removing the module from the backplane to prevent electrical damage.
• Use shielded cabling for all I/O connections to minimize electromagnetic interference (EMI) in high-noise industrial areas.
• Verify that the 24V DC power supply is stable and within the 19.2-30V range before energizing the unit.
• Ensure proper grounding of the chassis to the system earth to maintain signal integrity and safety.

FAQ

What communication protocols are supported by this unit?

The PS700 1JNL100175-851 supports PROFINET IO and Modbus TCP protocols for seamless integration into standard industrial networks.

What is the primary function of this module?

This is a Mach 3 Distributed I/O unit, which serves as a remote interface to collect digital and analog signals and communicate them to a central controller over an Ethernet-based network.
