The Allen-Bradley 1756-IN16 is a high-performance digital AC input module designed for integration within the ControlLogix platform. This module provides 16 isolated input points, specifically engineered to interface with 24V AC field devices in industrial automation environments. It offers reliable signal monitoring and is fully compatible with the standard ControlLogix chassis architecture.

Features

• 16-point digital AC input configuration.
• Designed for 24V AC nominal input voltage operations.
• Programmable input delay times of 9 or 18 milliseconds to filter noise and bounce.
• Wide operating voltage range from 10 to 30V AC.
• Robust, industry-standard ControlLogix form factor for seamless rack mounting.

Applications

This module is widely utilized in manufacturing and process control systems where AC-based sensors, limit switches, or pushbuttons require integration into a programmable logic controller. Its programmable delay feature makes it particularly effective in environments with electrical noise or mechanical contact bounce.

Technical Specifications

Installation Guidelines

• Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
• Ensure the module is fully seated in the chassis slot and secured with the top and bottom latching mechanisms.
• Use appropriate shielded cabling for field wiring to minimize electromagnetic interference (EMI).
• Verify that the input voltage levels do not exceed the 10-30V AC operating range specified for this unit.
• Maintain proper ventilation around the chassis to ensure optimal operating temperatures.

FAQ

What is the primary function of the 1756-IN16?
This module serves as a bridge between 24V AC field devices and the ControlLogix PLC system, converting AC signals into logic-level data for the controller.

Can I adjust the input response time?
Yes, the module supports programmable input delay settings of either 9 or 18 milliseconds, allowing for flexibility based on the specific requirements of your application.
