The 1769-HSC is a high-speed counter module for CompactLogix systems, designed for encoder, pulse, and rate measurement applications. It supports high-speed quadrature and pulse counting with fast local...
التوافر: الكمية المتبقية: 99
توصيل موثوق به في جميع أنحاء العالم
ضمان استرداد الأموال خلال 30 يومًا
هل تحتاج إلى مزيد من التفاصيل؟ اقرأ سياسة الشحن وسياسة الاسترداد الكاملة.
The 1769-HSC is a high-speed counter module for CompactLogix systems, designed for encoder, pulse, and rate measurement applications. It supports high-speed quadrature and pulse counting with fast local processing for accurate position and motion control.
| Parameter | Specification |
|---|---|
| Part Number | 1769-HSC |
| Number of Counters | 2 Quadrature or 4 Pulse/Direction |
| Input Voltage | 5V DC or 24V DC |
| Maximum Frequency | 1 MHz (Counter), 250 kHz (Quadrature) |
| Onboard Outputs | 4 Fast 24V DC Outputs |
| Input Impedance | 250 Ω (5V), 2.5 kΩ (24V) |
| Backplane Current Draw | 425 mA at 5.1V |
| Isolation | 30V Continuous |
| Weight | 0.20 kg |
High-speed local signal processing
Supports encoder and pulse applications
Fast onboard output response
Flexible voltage and counting modes
Easy integration with Studio 5000
Can the module accept 5V encoder signals?
Yes. The 1769-HSC supports both 5V DC and 24V DC input devices.
What are the onboard outputs used for?
They provide ultra-fast response for target count triggering without PLC scan delays.
Does the module support quadrature encoders?
Yes. It supports two quadrature encoder channels.
Is this product 100% Brand New?
Yes. This 1769-HSC module is supplied in 100% Brand New condition with a 2-year warranty.
