Description

The Allen-Bradley 194R-J400-1753 is a high-performance fused disconnect switch designed for industrial power distribution and motor control applications. This 400 A, 3-pole unit provides reliable circuit isolation and overcurrent protection when equipped with appropriate Class J fuses. Engineered for durability, this open-type switch is suitable for integration into industrial control panels and enclosures requiring robust disconnect capabilities.

Features

• Rated for 400 A current capacity
• Configured for 3-pole operation
• Integrated Class J fuse clips for standardized overcurrent protection
• Open-type construction for flexible panel mounting
• Designed for high-duty industrial disconnect applications

Technical Specifications

Installation Guidelines

• Ensure the power supply is completely isolated and locked out before attempting installation or maintenance.
• Mount the switch in an appropriate enclosure that provides sufficient protection against environmental contaminants and accidental contact.
• Verify that all electrical connections are tightened to the manufacturer's specified torque values to prevent overheating.
• Ensure adequate clearance around the switch to allow for heat dissipation and safe operation of the handle mechanism.
• Use appropriate wire gauges and terminal lugs compatible with the 400 A rating of the device.
• Always verify that the installed Class J fuses match the circuit requirements and the switch ratings.

FAQ

What type of fuses does the 194R-J400-1753 use?

This model is specifically designed for use with Class J fuses, which are installed directly into the integrated fuse clips.

Is this switch enclosed?

No, this is an open-type disconnect switch intended for mounting within a larger industrial control panel or cabinet.

What is the primary function of this device?

The 194R-J400-1753 serves as a manual disconnect switch, allowing for the physical isolation of electrical circuits for maintenance or emergency shutdown, while providing fused overcurrent protection.
