Description

The Allen-Bradley 2711C-RCSD is an industrial-grade USB-to-SD card memory adapter designed to expand the storage capabilities and facilitate local data management for the PanelView Component human-machine interface (HMI) terminal family. This compact hardware accessory establishes a secure bridge for connecting standard Secure Digital (SD) storage media via the terminal's integrated USB host port. It provides a dependable medium for localized data logging, alarm history archiving, runtime recipe transfers, and application backup operations in diverse industrial environments.

Features

• Plug-and-play architecture with integrated USB Type-A male connector.
• Standard SD card slot for external memory expansion.
• Enables direct configuration cloning and application downloads without a network link.
• Durable, molded protective housing designed for industrial control panel environments.
• High mechanical retention to withstand standard factory vibrations.

Applications

The 2711C-RCSD is suitable for use in various automation sectors, including wastewater treatment, automotive manufacturing, commercial packaging lines, and food processing. It is specifically designed for use with the PanelView Component terminal series (C200, C300, C400, C600, and C1000).

Technical Specifications

Installation Guidelines

• Ensure the PanelView Component terminal is powered on or in a state that supports USB peripheral detection before insertion.
• Insert the USB male connector firmly into the terminal's USB host port until fully seated.
• Insert the SD card into the adapter slot with the correct orientation as indicated on the housing.
• Avoid excessive mechanical strain on the adapter housing once installed.
• The device is intended for use within protected control panels; ensure the environment remains within the specified temperature and humidity ranges.

FAQ

Does this adapter support all SD card types?

The adapter is designed for standard Secure Digital (SD) memory cards. Compatibility with high-capacity SDHC or SDXC cards may depend on the specific firmware version of the host PanelView Component terminal.

Is this adapter suitable for outdoor use?

No, the 2711C-RCSD carries an IP00 rating and is designed for indoor use within protected control panels or terminal enclosures only.
