The Allen-Bradley 2711C-RG2F is an industrial-grade protective anti-glare screen overlay specifically engineered for PanelView Component graphic operator terminals. This maintenance accessory provides a robust physical barrier that shields the terminal's integrated display window and touch membrane against environmental hazards, surface scratching, and fluid ingress. By neutralizing harsh overhead reflections and diffusing intense light, the overlay ensures consistent visual clarity for operators in demanding industrial environments.

Features

• Precision-cut design tailored for PanelView Component C200 and C300 micro-terminal platforms.
• Advanced textured matte finish reduces glare and improves readability under high-intensity lighting or direct sunlight.
• Durable polymer construction resistant to standard industrial cleaning agents, oils, and airborne debris.
• Maintains full touch sensitivity and actuation profiles for both capacitive and resistive screen types.
• Flush-mount adhesive perimeter ensures a secure fit without air pockets or optical distortion.

Applications

This overlay is suitable for use in diverse automation sectors, including chemical processing, metal machining, food and beverage production, and outdoor pump station control panels. It is ideal for environments where screen protection and glare reduction are critical for operational safety and equipment longevity.

Technical Specifications

Installation Guidelines

• Ensure the terminal display surface is clean, dry, and free of dust or grease before application.
• Use a lint-free cloth and mild industrial cleaner to prepare the bezel area.
• Carefully align the overlay with the terminal screen edges before applying pressure to the adhesive perimeter.
• Smooth the overlay from the center outward to ensure a bubble-free seal.
• Power down the HMI terminal during installation to prevent accidental touch inputs or screen activation.

FAQ

Does this overlay affect the touch screen sensitivity?

No, the 2711C-RG2F is designed to maintain 100% actuation retention for both tactile keypad and touch-cell matrix inputs, ensuring no loss of responsiveness.

Is this overlay compatible with all PanelView models?

This specific model is designed for the PanelView Component C200 and C300 series. Please verify your terminal model number before installation.
