The Allen-Bradley 2711E-UT14ET10 is a specialized hardware migration and adapter bezel kit designed to streamline the modernization of industrial control stations. This kit enables the seamless retrofitting of a 10.4-inch PanelView 1000e touchscreen terminal into an existing enclosure cutout originally designed for a 14-inch PanelView 1400e terminal. By providing a precise mechanical transition, this assembly eliminates the need for extensive sheet-metal modification or complete enclosure replacement, preserving the structural integrity and environmental sealing of the control cabinet.

Features

• Mechanical Retrofit Compatibility: Engineered specifically to bridge the dimensional gap between legacy 14-inch cutouts and current 10.4-inch PanelView 1000e HMI units.
• Rugged Construction: Fabricated from heavy-gauge carbon steel with an industrial-grade, anti-corrosive powder coating for long-term durability in harsh environments.
• Environmental Integrity: Includes high-density compression gaskets and perimeter stud mounts to maintain NEMA Type 4X and Type 12 enclosure ratings.
• Vibration Resistance: Designed to stabilize the HMI terminal within the panel, reducing mechanical stress on internal circuitry during continuous operation.

Applications

This migration kit is intended for use in heavy-duty industrial sectors, including automotive manufacturing, water treatment facilities, and chemical processing plants. It is ideal for maintenance teams and system integrators tasked with upgrading legacy HMI hardware while minimizing downtime and avoiding costly panel re-engineering.

Installation Guidelines

• Ensure the existing enclosure cutout is clean and free of debris before mounting the adapter plate.
• Verify that the compression gaskets are seated correctly to maintain the required NEMA environmental seal.
• Use the provided perimeter studs and locking hardware to distribute fastening pressure evenly around the bezel.
• Ensure the HMI terminal is properly grounded to the enclosure frame to mitigate EMI/RFI interference.
• Verify that the operating environment remains within the specified 0 to 50 deg C temperature range.

Technical Specifications

FAQ

Does this kit require cutting the existing enclosure? No, the 2711E-UT14ET10 is designed to fit the existing 14-inch cutout, acting as an adapter to accommodate the smaller 10.4-inch HMI footprint.

Is this kit compatible with non-touchscreen models? This specific kit is engineered for the physical envelope and sealing profiles of the PanelView 1000e Touchscreen terminal series.
