The Allen-Bradley 2711P-K10C4D2 is a high-performance operator interface terminal from the PanelView Plus 1000 series, engineered for reliable visualization and control in industrial automation environments. This unit features a 10.4-inch active-matrix color TFT display and a robust keypad interface, designed to withstand the rigors of heavy-duty applications such as chemical processing, power generation, and automated manufacturing.

Features

• 10.4-inch color TFT display providing clear, high-resolution process visualization.
• Tactile keypad input for precise operator control in industrial settings.
• Integrated 10/100Base-T Ethernet and RS-232 serial communication ports for flexible connectivity.
• Dual USB host ports for peripheral support and data transfer.
• DC power input (18-32 VDC) suitable for standard industrial control cabinets.
• 128 MB internal memory for application storage and runtime execution.

Applications

This terminal is suitable for monitoring and controlling complex industrial processes. It is commonly deployed in systems requiring localized operator interaction, such as PLC-based machine control, SCADA data monitoring, and distributed control system (DCS) interface points.

Technical Specifications

Installation Guidelines

• Ensure the panel cutout is prepared according to the manufacturer's specifications to maintain the NEMA/IP rating.
• Use a clean, dry, and vibration-free mounting surface.
• Verify that the power supply is within the 18-32 VDC range before connection to prevent damage.
• Maintain proper clearance around the unit for adequate ventilation and cooling.
• Ensure the unit is properly grounded to the cabinet chassis to mitigate EMI/RFI interference.
• Always disconnect power before installing or removing communication cables or peripheral devices.

FAQ

What is the primary power requirement for this unit? The 2711P-K10C4D2 requires a DC power supply between 18 and 32 VDC, with 24 VDC being the nominal operating voltage.

Can the backlight be replaced? Yes, this model uses a field-replaceable CCFL backlight (Part Number: 2711P-RL10C).

What communication options are available? This unit includes an integrated 10/100Base-T Ethernet port, an RS-232 serial port, and two USB host ports for external device connectivity.
