Description

The Allen-Bradley 2094-BM03-S is a Kinetix 6000 multi-axis servo drive module designed for high-performance motion control applications. This axis module features integrated Safe Torque-Off functionality, providing a robust solution for safety-rated machine operations. It is engineered to operate within a 460 VAC, 3-phase power environment, delivering reliable power conversion and precise motor control for demanding industrial automation systems.

Features

• Integrated Safe Torque-Off (STO) feature for enhanced machine safety.
• Designed for use within the Kinetix 6000 multi-axis drive system.
• Supports high-bandwidth performance with a 1300 Hz current loop and 500 Hz velocity loop.
• Robust power output capabilities suitable for high-demand motion profiles.
• Optimized for 360-480V AC 3-phase input voltage ranges.

Technical Specifications

Installation Guidelines

• Ensure the module is mounted in an enclosure that provides adequate ventilation and cooling to maintain ambient operating temperatures.
• Verify that all power connections are secure and that the DC bus voltage is within the specified range before energizing.
• Always disconnect and lock out power sources before installing or removing the module from the Kinetix 6000 power rail.
• Use appropriate shielded cabling for motor and feedback connections to minimize electromagnetic interference (EMI).
• Ensure proper grounding of the drive chassis to the system common ground point to maintain signal integrity and safety.

FAQ

What is the primary function of the 2094-BM03-S?

This unit is an axis module for the Kinetix 6000 servo drive system, responsible for controlling the speed, position, and torque of connected servo motors in a multi-axis configuration.

Does this module include safety features?

Yes, the 2094-BM03-S includes the Safe Torque-Off (STO) feature, which allows for the removal of power to the motor while maintaining the drive's connection to the control network.
