The Allen-Bradley PM3398B-6-1-3-E is a high-performance power supply module engineered for integration within Kinetix servo drive systems. This unit provides reliable DC power conversion, ensuring stable operation for industrial motion control applications requiring precise voltage regulation and high efficiency.

Features

• Auto-ranging AC input capability supporting global voltage standards (100-240V AC).
• High-efficiency power conversion architecture exceeding 90% typical efficiency.
• Robust thermal management design suitable for operation in demanding industrial environments.
• Integrated protection features to ensure consistent output stability under varying load conditions.

Technical Specifications

Installation Guidelines

• Ensure the power supply is installed in a clean, dry environment with adequate airflow to maintain operating temperatures within the specified range.
• Always disconnect all power sources before performing installation, wiring, or maintenance to prevent electrical shock.
• Verify that input voltage matches the auto-ranging specifications before energizing the unit.
• Use appropriate wire gauges and ensure all terminal connections are tightened to the manufacturer's recommended torque specifications.
• Maintain proper grounding practices to minimize electromagnetic interference (EMI) and ensure system safety.

FAQ

What is the primary function of the PM3398B-6-1-3-E?

This module acts as a dedicated power supply unit for Kinetix servo drive systems, converting standard AC line power into a stable 24V DC output for control and auxiliary circuitry.

Is this power supply suitable for high-temperature environments?

Yes, the unit is rated for operation in ambient temperatures ranging from -25 degC to +70 degC, making it suitable for most industrial cabinet installations.

What should I do if the output voltage fluctuates?

Ensure that the input AC supply is stable and within the 47-63Hz frequency range. If fluctuations persist, check all terminal connections for signs of oxidation or looseness, and verify that the load does not exceed the continuous 6A current rating.
