Description

The Allen-Bradley 2711P-K4M5D is a compact operator terminal from the PanelView Plus 400 series. Designed for industrial HMI applications, this unit features a 3.8-inch grayscale display and a dedicated keypad input interface, providing reliable visualization and control for machine-level operations. It is engineered to integrate seamlessly into automation systems requiring a robust, space-saving interface.

Features

• 3.8-inch grayscale display for clear process monitoring.
• Integrated keypad for tactile operator input in demanding environments.
• Equipped with an RS-232 communication port for connectivity with controllers and peripheral devices.
• 64 MB of onboard memory for application storage and runtime data.
• Clock accuracy rated at +/- 2 minutes per month.

Technical Specifications

Installation Guidelines

• Ensure the panel cutout is prepared according to the manufacturer's mounting template to maintain the required enclosure rating.
• Use appropriate gasket seals during installation to prevent ingress of dust or moisture.
• Ensure the terminal is mounted in a location with adequate ventilation to prevent overheating.
• Verify that the power supply voltage matches the specifications for this DC-powered unit before connection.
• Follow standard ESD precautions when handling the terminal to prevent damage to internal circuitry.
• Route communication cables away from high-voltage lines or sources of electromagnetic interference (EMI).

FAQ

What is the primary input method for this terminal?
The 2711P-K4M5D is equipped with a physical keypad for operator input, making it suitable for environments where tactile feedback is preferred over touchscreen interfaces.

Does this unit support color graphics?
No, this specific model features a grayscale display optimized for high-contrast text and simple graphical representations.
