The 1769-IF4I is a CompactLogix isolated analog input module with four individually isolated channels for voltage and current signals. It delivers high-accuracy analog data conversion while protecting the...
التوافر: الكمية المتبقية: 99
توصيل موثوق به في جميع أنحاء العالم
ضمان استرداد الأموال خلال 30 يومًا
هل تحتاج إلى مزيد من التفاصيل؟ اقرأ سياسة الشحن وسياسة الاسترداد الكاملة.
The 1769-IF4I is a CompactLogix isolated analog input module with four individually isolated channels for voltage and current signals. It delivers high-accuracy analog data conversion while protecting the control system from electrical noise and ground loop interference in industrial environments.
| Parameter | Specification |
|---|---|
| Part Number | 1769-IF4I |
| Number of Inputs | 4 Isolated Channels |
| Voltage Inputs | ±10V, 0-10V, 0-5V, 1-5V |
| Current Inputs | 0-20 mA, 4-20 mA |
| Resolution | 16-bit |
| Isolation Voltage | 30V AC / 30V DC |
| Backplane Current Draw | 145 mA at 5.1V / 125 mA at 24V |
| Conversion Type | Delta-Sigma |
| Mounting | DIN Rail or Panel Mount |
| Weight | 0.20 kg |
Individually isolated input channels
High-precision 16-bit analog conversion
Supports mixed voltage and current signals
Strong protection against electrical noise
Easy software configuration and calibration
Does the 1769-IF4I support thermocouples or RTDs?
No. It supports standard voltage and current analog signals only.
What is the advantage of isolated channels?
Isolation prevents signal interference and ground loop issues between devices.
Can channels use different signal types?
Yes. Each channel can be configured independently.
Is this product 100% Brand New?
Yes. This 1769-IF4I module is supplied in 100% Brand New condition with a 2-year warranty.
