The Honeywell 05701-A-0283 is a sensor drive module designed for industrial gas detection and monitoring systems. It powers external 4–20 mA gas sensors and processes concentration signals for...
التوافر: الكمية المتبقية: 99
توصيل موثوق به في جميع أنحاء العالم
ضمان استرداد الأموال خلال 30 يومًا
هل تحتاج إلى مزيد من التفاصيل؟ اقرأ سياسة الشحن وسياسة الاسترداد الكاملة.
The Honeywell 05701-A-0283 is a sensor drive module designed for industrial gas detection and monitoring systems. It powers external 4–20 mA gas sensors and processes concentration signals for toxic and flammable gas detection. We supply this module as 100% brand new and original for reliable industrial operation.
| Specification | Details |
|---|---|
| Brand / Manufacturer | Honeywell / Analytics |
| Model Number | 05701-A-0283 |
| Product Type | Sensor Drive Module |
| Condition | 100% Brand New and Original |
| Supported Input Type | 4–20 mA current loop sensors |
| Signal Range | 0 to 25 mA |
| Input Voltage | 18V to 32V DC |
| Output Compliance | 40V |
| Power Consumption | 3.25W maximum |
| Operating Temperature | -25°C to +55°C |
| Weight | 0.165 kg |
40V output compliance supports stable 4–20 mA transmission over long cable distances.
Supports 0–25 mA signal monitoring for fault and over-range detection.
Efficient 3.25W design reduces cabinet heat generation.
Operates reliably in harsh environments from -25°C to +55°C.
No, it operates directly from standard 18V–32V DC industrial power supplies.
Yes, it supports 20%–90% RH non-condensing environments.
It supports standard industrial gas sensors using 4–20 mA current loop communication.
