The Bently Nevada 3300/16 Dual Vibration Monitor is a rack-mounted module engineered for continuous radial shaft vibration measurement in critical rotating machinery, including turbines, compressors, and pumps. This dual-channel monitor provides essential protection by comparing real-time vibration data against pre-configured Alert and Danger setpoints, facilitating both equipment safety and predictive maintenance.

Features

• Dual-channel radial vibration monitoring for comprehensive shaft analysis.
• Configured for proximity probe inputs via Proximitor sensors.
• Integrated alarm logic with relay actuation for Alert and Danger conditions.
• Front-panel LED indicators for system status: OK, Bypass, Alert, and Danger.
• Standardized 3300 rack system compatibility.

Applications

This module is designed for use in industrial environments where monitoring shaft displacement is critical to prevent mechanical failure. Common applications include large steam and gas turbines, centrifugal compressors, and high-speed pumps where vibration trends are key indicators of machine health.

Technical Specifications

Installation Guidelines

• Ensure the 3300 rack is powered down before inserting or removing the module to prevent electrical damage.
• Ensure proper grounding of the rack system to mitigate EMI and ensure signal integrity.
• Use shielded cabling for proximity probe inputs to minimize noise interference.
• Verify that the module is fully seated in the rack slot and that the front-panel connectors are securely fastened.
• Maintain adequate ventilation within the cabinet to ensure the module operates within the specified 0 to 60 deg C temperature range.

FAQ

What does the 11-01-01-00-00-00 suffix indicate?

These codes define the specific configuration of your module, including the XY radial vibration setup, standard agency approval, proximity probe input compatibility, and default relay/barrier settings.

Can this module be used for non-radial vibration measurements?

The 3300/16 is specifically optimized for radial shaft vibration. For other measurement types, please consult the Bently Nevada 3300 series documentation for the appropriate module model.
