Description

The Bently Nevada 3300/16-12-01-00-00 is a dual-channel vibration monitoring module engineered for the 3300 series rack system. This unit provides critical machinery protection by continuously monitoring radial shaft vibration, specifically configured to interface with proximity probe transducers. It is widely utilized in industrial environments to safeguard rotating equipment such as turbines, large compressors, and centrifugal pumps.

Features

• Dual-channel input architecture designed for X-Y radial vibration monitoring.
• Integrated alarm logic with dedicated Alert and Danger setpoint comparisons.
• Front-panel LED indicators providing real-time status for OK, Bypass, Alert, and Danger conditions.
• Standard relay output configuration for automated machinery shutdown or alarm notification.
• Proportional 4-20 mA outputs for integration into external DCS or PLC monitoring systems.

Applications

This monitor is essential for predictive and preventative maintenance strategies in heavy industry. It is frequently applied in the continuous monitoring of shaft displacement in high-speed rotating machinery, ensuring early detection of mechanical issues before catastrophic failure occurs.

Technical Specifications

Installation Guidelines

• Ensure the 3300 rack is powered down before inserting or removing the monitor module to prevent electrical damage.
• Verify that all proximity probe wiring is shielded and properly grounded to minimize EMI/RFI interference.
• Handle the module using standard ESD precautions to protect internal circuitry.
• Confirm that the module is fully seated in the rack backplane to ensure reliable signal and power connectivity.

FAQ

What does the 3300/16-12-01-00-00 configuration represent?
This model code specifies a dual vibration monitor optimized for proximity probe inputs with standard relay and agency approval options suitable for typical industrial machinery protection.

Is this module compatible with other 3300 series components?
Yes, this module is designed for integration within the Bently Nevada 3300 rack system. Ensure your rack power supply and backplane are compatible with the 3300/16 series requirements.
