Description

The Bently Nevada 330103-05-13-10-02-00 is a high-performance 3300 XL 8 mm proximity probe designed for critical machinery protection and condition monitoring applications. This probe is engineered to provide precise, non-contact measurements of shaft displacement, position, and vibration in rotating equipment such as turbines, compressors, and pumps. As part of the 3300 XL series, it offers improved reliability and compatibility with standard Bently Nevada proximity transducer systems.

Features

• 8 mm probe tip diameter for high sensitivity and wide linear range.
• M10 x 1 thread configuration for secure mounting in machinery housings.
• Equipped with a miniature coaxial ClickLoc connector for reliable signal transmission.
• Standard cable construction designed for industrial environments.
• Designed for seamless integration with 3300 XL proximity transducer systems.

Technical Specifications

Installation Guidelines

• Ensure the probe is installed in a rigid mounting bracket to prevent mechanical resonance.
• Handle the probe tip with care; avoid physical impact or scratching, as this can affect measurement accuracy.
• Route the coaxial cable away from high-voltage power lines and sources of electromagnetic interference (EMI).
• Ensure the ClickLoc connector is fully seated and tightened to maintain signal integrity.
• Verify that the probe gap is set according to the specific machine monitoring requirements and the transducer system calibration.
• Always power down the associated monitoring system before disconnecting or replacing the probe to prevent electrical damage.

FAQ

What is the primary function of the 330103-05-13-10-02-00 probe?

This probe is used to measure the distance between the probe tip and a conductive target, typically a rotating shaft, to monitor vibration and position parameters within a Bently Nevada 3300 XL transducer system.

Is this probe compatible with older 3300 series systems?

The 3300 XL probes are designed to be backward compatible with 3300 series systems, provided the extension cable and proximity sensor (proximitor) are also compatible with the XL series specifications.
