Description

The Bently Nevada 330905-06-14-10-02-00 is a factory-terminated sensor cable specifically engineered for the 3300 XL NSv (Near-field Sensing) Proximity Probe system. This cable facilitates reliable signal transmission between the NSv proximity probe and the Proximitor sensor, serving as a critical component in vibration and displacement monitoring applications. It is optimized for small-shaft machinery where space is limited and high-precision measurement is required.

Features

• Designed for 3300 XL NSv proximity probe systems.
• Armored coaxial cable construction for enhanced durability in industrial environments.
• Integrated EMI/RFI shielding to maintain signal integrity.
• Factory-terminated connectors ensure consistent electrical performance.
• Suitable for monitoring shaft diameters smaller than 51 mm.

Applications

• Small-shaft machinery vibration monitoring.
• Displacement measurement in tight installation spaces.
• Turbomachinery protection systems requiring API 670 compliance.

Technical Specifications

Installation Guidelines

• Ensure the cable is routed away from high-voltage power lines to prevent electromagnetic interference.
• Use appropriate cable clamps to secure the armored cable and prevent mechanical stress on the connectors.
• Verify that all connections are clean and fully seated before system startup.
• Handle with care to avoid kinking or crushing the coaxial cable, as this can alter the impedance and affect measurement accuracy.
• Ensure the system is powered down before disconnecting or connecting the probe cable to the Proximitor sensor.

Compliance and Certifications

• API 670 compliant.
• EMC Compliance: EN 61000-6-2 (Immunity), EN 61000-6-4 (Emissions).
• RoHS Directive 2011/65/EU compliant.
• CSA/NRTL/C Class I, Zone 2 safety approvals (system dependent).

FAQ

What is the primary purpose of the 330905-06-14-10-02-00 cable?

This cable is a specialized extension component for the Bently Nevada 3300 XL NSv proximity probe system, used to transmit signals from the probe to the Proximitor sensor in small-shaft vibration monitoring applications.

Can this cable be used in high-temperature environments?

Yes, the cable is rated for operation in temperatures ranging from -35 degC to +200 degC, making it suitable for most industrial machinery environments.
