Description

The Bently Nevada 3500/93 135799-01 is a Display Interface Module designed for the 3500 Machinery Protection System. This module serves as the critical communication link between the 3500 rack and the 3500/94 VGA Display unit. It facilitates the transfer of system data, allowing operators to visualize real-time machinery monitoring information, alarm statuses, and configuration data on a remote display.

Features

• Provides high-speed data communication between the 3500 rack and the VGA display unit.
• Supports the visualization of rack-wide monitoring data and system events.
• Designed for integration within the standard 3500 series rack architecture.
• Includes dedicated communication ports for reliable interface connectivity.
• Robust design suitable for demanding industrial environments.

Technical Specifications

Installation Guidelines

• Ensure the 3500 rack is powered down before inserting or removing the module to prevent electrical damage.
• Verify that the module is correctly seated in the designated rack slot and that the front panel screws are tightened to ensure proper grounding.
• Use appropriate shielded cabling for display communication to minimize EMI/RFI interference.
• Maintain adequate ventilation within the cabinet to ensure the module operates within its specified temperature range.
• Handle with standard ESD precautions to protect sensitive electronic components.

FAQ

Is the 3500/93 135799-01 still in production?

No, this model has been discontinued by the manufacturer. We provide high-quality surplus or refurbished units to support legacy system maintenance.

What is the primary function of this module?

The 3500/93 acts as the interface bridge that allows the Bently Nevada 3500 system to output data to a 3500/94 VGA display, enabling local monitoring of vibration and process parameters.
