The Woodward CSC3HUWB, also cataloged as the CSC3HUWB SEG Controller Module, operates as a dedicated hardware component for analog signal processing and discrete logic execution within industrial automation systems.
التوافر: الكمية المتبقية: 10
توصيل موثوق به في جميع أنحاء العالم
ضمان استرداد الأموال خلال 30 يومًا
هل تحتاج إلى مزيد من التفاصيل؟ اقرأ سياسة الشحن وسياسة الاسترداد الكاملة.
The Woodward CSC3HUWB, also cataloged as the CSC3HUWB SEG Controller Module, operates as a dedicated hardware component for analog signal processing and discrete logic execution within industrial automation systems.
| Parameter | Specification |
|---|---|
| Model | CSC3HUWB |
| Brand | Woodward |
| Origin | USA |
| Weight | 1.5kg |
| Dimensions | 120 mm x 100 mm x 40 mm (4.7 in x 3.9 in x 1.6 in) |
| Operating Temp | -20 to +60 deg C |
| Power Consumption | 5 W |
| Supply Voltage | 24 VDC |
| Storage Temperature | -40 to +85 deg C |
| Relative Humidity | 10 to 90% RH (non-condensing) |
| Shock Resistance | 15G for 11ms |
| Analog Inputs | 4 channels (0-10 V) |
| Digital Outputs | 8 channels (24 V) |
The Woodward CSC3HUWB module processes 4 analog input channels (0-10 V) and drives 8 discrete 24 V digital output channels to deliver high-speed actuator loop feedback response. Interfacing directly with field actuators and primary control loops, the unit evaluates voltage signals with minimal latency to adjust system parameters under dynamic load changes. Its low 5 W power consumption and 15G shock resistance ensure reliable signal conditioning and deterministic output execution even in high-vibration industrial environments.
Q: What is the operating power supply requirement for the Woodward CSC3HUWB module?
A: The module requires an auxiliary input supply voltage of 24 VDC and consumes 5 W of power during standard operation.
Q: What input and output channel capacity is available on this SEG controller module?
A: The hardware is equipped with 4 analog input channels accepting 0 to 10 V signals and 8 digital output channels delivering 24 V signals.
Q: What are the mechanical shock and operating temperature limits for the unit?
A: The module is rated for full functionality across an operating temperature range of -20 to +60 deg C and features shock resistance up to 15G for an 11 ms duration.
