Description

The Emerson DeltaV KJ4002X1-BF2 (12P3866X012) is a specialized bus extender cable assembly designed for the DeltaV distributed control system. This bottom-mount cable assembly facilitates reliable communication and power distribution between system components, ensuring the integrity of the I/O bus architecture. As a critical interconnect component, it is engineered to meet the rigorous connectivity standards required for industrial automation environments.

Features

• Designed for seamless integration with DeltaV system architecture
• Bottom-mount configuration for optimized cabinet cable routing
• Robust construction for reliable signal transmission
• Standardized connector interfaces for secure installation

Technical Specifications

Installation Guidelines

• Ensure the control system is powered down before connecting or disconnecting the bus extender cable to prevent electrical arcing or damage to communication ports.
• Route the cable away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
• Verify that the connectors are fully seated and locked into the corresponding ports on the I/O carrier or controller assembly.
• Avoid sharp bends or excessive tension on the cable during installation to prevent internal conductor fatigue.
• Follow standard ESD (Electrostatic Discharge) precautions when handling the cable connectors to protect sensitive system electronics.

FAQ

Is this cable assembly still in production?

No, the KJ4002X1-BF2 is marked as discontinued by the manufacturer. We provide these units as spare parts for legacy system maintenance and support.

What is the primary function of this cable?

This is a bus extender cable used to connect and extend the I/O bus communication path between DeltaV hardware modules, specifically designed for bottom-entry cabinet configurations.
