Description

The Emerson DeltaV KJ4006X1-BC1 (12P4720X062) is an 8-channel fused terminal block designed for use within the DeltaV distributed control system environment. This component provides reliable field wiring termination and circuit protection for I/O signals, ensuring robust connectivity and safety in industrial process control applications.

Features

• 8-channel configuration for high-density signal termination.
• Integrated fusing for individual channel protection.
• Designed for operation in demanding industrial environments with high resistance to vibration and shock.
• Supports field power up to 60 VDC at 1 A per channel.
• Compliant with ISA-S71.04-1985 Class G3 standards for airborne contaminants.

Technical Specifications

Installation Guidelines

• Ensure the system power is disconnected before installing or removing the terminal block from the mounting rail.
• Verify that all field wiring is properly secured to the terminals to prevent intermittent connections.
• Maintain proper clearance for airflow to ensure the module operates within the specified temperature range.
• Handle with care to avoid electrostatic discharge (ESD) damage to sensitive electronic components in the vicinity.
• Ensure that the terminal block is mounted in an environment that meets the specified airborne contaminant ratings (Class G3).

FAQ

What is the primary function of the KJ4006X1-BC1?
This module serves as a fused terminal block for the DeltaV system, providing 8 channels of signal termination and circuit protection for field devices.

Can this terminal block be used in high-vibration environments?
Yes, the unit is rated for industrial vibration levels, specifically 1mm peak-to-peak from 2 to 13.2Hz and 0.7g from 13.2 to 150Hz.
