Description

The GE Fanuc IC693CPU313 is an integrated baseplate featuring an embedded Turbo CPU designed for the Series 90-30 Programmable Logic Controller (PLC) family. This unit combines the physical backplane functionality with a high-performance processor, providing a compact solution for automation control systems requiring efficient logic execution and I/O management.

Features

• Embedded Turbo CPU architecture for reliable control processing.
• Five (5) integrated I/O slots for module expansion.
• Typical scan rate of 0.6 ms per 1K of Boolean logic.
• Processor speed rated at 10 MHz.
• Supports up to 64 words of analog input (%AI) and 32 words of analog output (%AQ).
• Includes one built-in serial port for communication tasks.

Technical Specifications

Installation Guidelines

• Ensure the PLC system is powered down before installing or removing any modules from the baseplate slots.
• Mount the baseplate in a clean, dry environment with adequate ventilation to prevent overheating.
• Verify that the backplane connectors are free of debris and properly aligned before seating modules.
• Maintain proper grounding practices for the rack to minimize electromagnetic interference (EMI) and ensure signal integrity.
• Use shielded cables for communication ports to protect against electrical noise in industrial environments.

FAQ

What is the primary function of the IC693CPU313?

This unit serves as a baseplate for the Series 90-30 system that includes an embedded Turbo CPU, allowing it to act as both the physical mounting rack for I/O modules and the central processing unit for the PLC system.

Does this unit require an external power supply?

The baseplate operates on a +5VDC bus voltage, which is typically supplied by the system power supply module installed within the rack configuration.
