Description

The General Electric IC694MDL655 is a high-density discrete input module designed for the PACSystems RX3i control platform. This module provides 32 points of discrete input, organized into four isolated groups of eight inputs each. It is engineered to interface with a wide range of field devices, supporting both positive and negative logic configurations to ensure flexibility in industrial control applications.

Features

• 32 discrete input channels organized into 4 groups of 8.
• Supports both positive and negative logic input types.
• Wide input voltage range compatibility (0-30 VDC nominal, up to 60 VDC).
• Fast response time of 2 ms (maximum) for both On and Off transitions.
• Integrated LED status indicators for each channel to facilitate rapid diagnostics.
• Optical isolation between field side and backplane to protect control circuitry.

Technical Specifications

Installation Guidelines

• Ensure the PACSystems RX3i rack power is disconnected before installing or removing the module.
• The module must be seated firmly into the RX3i backplane slot and secured using the integrated locking mechanism.
• Use shielded cabling for field inputs to minimize EMI interference, especially in high-noise industrial environments.
• Maintain proper cable routing to prevent signal degradation and ensure compliance with maximum cable length specifications (30 meters).
• Handle the module using ESD-safe practices to prevent damage to sensitive internal electronic components.

FAQ

What is the primary function of the IC694MDL655?

The IC694MDL655 is a high-density discrete input module used to monitor the status of 32 field devices and communicate that state to the PACSystems RX3i PLC controller.

Can this module be used with both PNP and NPN sensors?

Yes, the module supports both positive and negative logic, allowing it to interface with a variety of standard industrial sensors and switches.

What is the maximum cable length for inputs?

The recommended maximum cable length for field inputs connected to this module is 30 meters to ensure signal integrity and proper response times.
