Description

The General Electric IC698CPE030-JP is a high-performance CPU module designed for the PACSystems RX7i PLC platform. This controller leverages a 600 MHz Pentium M microprocessor to provide robust processing power for complex automation tasks, including advanced floating-point mathematics. It is engineered to serve as the central processing unit in demanding industrial control environments, offering high-speed execution and reliable memory management.

Features

• 600 MHz Pentium M microprocessor for high-speed logic execution.
• 64 MB of user memory, RAM, and Flash memory for extensive program storage.
• Integrated Ethernet port supporting 10/100 Mbps data rates with auto-negotiation.
• Dual serial ports (RS-232 and RS-485) for flexible communication with peripheral devices.
• Supports up to 16 simultaneous FTP and web server connections.
• Capable of managing up to 512 program blocks for complex application architectures.

Applications

The IC698CPE030-JP is primarily utilized in the PACSystems RX7i PLC system, suitable for large-scale industrial automation, process control, and high-speed manufacturing applications where precise logic control and data handling are required.

Technical Specifications

Installation Guidelines

• Ensure the RX7i rack is powered down before inserting or removing the CPU module to prevent electrical damage.
• Handle the module using ESD-safe practices to protect sensitive internal components.
• Ensure the module is fully seated in the designated backplane slot and secured with the integrated locking mechanism.
• Maintain adequate ventilation around the rack to prevent overheating during operation.
• Use shielded communication cables for Ethernet and serial connections to minimize EMI interference in industrial environments.

FAQ

What is the primary function of the IC698CPE030-JP?

This module acts as the central processor for the GE PACSystems RX7i PLC, responsible for executing user logic, managing I/O memory, and facilitating communication via Ethernet and serial interfaces.

Does this controller support floating-point math?

Yes, the IC698CPE030-JP is designed to support floating-point mathematics, making it suitable for applications requiring precise analog data processing.
