Description

The General Electric IC693PBS201 is a PROFIBUS DP Slave module designed for the Series 90-30 Programmable Logic Controller (PLC) system. This module enables the Series 90-30 PLC to function as a slave device on a PROFIBUS DP network, allowing for seamless data exchange with a PROFIBUS master controller. It is engineered to provide efficient, high-speed communication in industrial automation environments.

Features

• Designed specifically for GE Series 90-30 PLC backplanes.
• Supports PROFIBUS DP slave communication protocol.
• Equipped with two communication ports for network connectivity.
• Occupies a single slot on the PLC baseplate.
• Supports up to 244 bytes of input data.

Applications

This module is typically used in distributed control systems where the Series 90-30 PLC acts as a remote I/O station or a subordinate controller within a larger PROFIBUS network architecture. Common applications include manufacturing, process control, and material handling systems requiring integration with third-party PROFIBUS master devices.

Technical Specifications

Installation Guidelines

• Ensure the PLC system is powered down before installing or removing the module to prevent electrical damage.
• The module is designed for installation in any available slot on a Series 90-30 baseplate.
• Ensure the module is fully seated and the locking tabs are engaged to maintain a secure connection to the backplane.
• Use appropriate shielded PROFIBUS cabling to minimize EMI interference in industrial environments.
• Handle the module using ESD-safe practices to prevent damage to sensitive electronic components.

FAQ

What is the primary function of the IC693PBS201?

The IC693PBS201 acts as a PROFIBUS DP slave interface, allowing a GE Series 90-30 PLC to communicate as a slave device on a PROFIBUS network.

Does this module require a specific slot?

It can be installed in any standard slot on a Series 90-30 baseplate, as it occupies a single slot width.

How much data can this module handle?

The module supports up to 244 bytes of input data for communication with the PROFIBUS master.
