The General Electric IC660TBD110 is a Genius Block I/O module designed for industrial automation control systems. This module provides 16 input circuits, specifically engineered for 115 VAC operation within the Genius I/O series. It serves as a reliable interface for monitoring AC signal states in distributed control environments.

Features

• 16-circuit input capacity for high-density signal monitoring.
• Designed for 115 VAC nominal operation with an operating range of 93 to 132 VAC.
• Supports standard industrial power frequencies from 47 to 63 Hz.
• Robust isolation rating of 1500 Volts between input and ground for enhanced system protection.
• Optimized for integration within the GE Genius I/O distributed architecture.

Technical Specifications

Installation Guidelines

• Ensure the system power is completely disconnected before installing or removing the module from the I/O bus.
• Mount the block in a location that allows for adequate airflow to manage the 28W maximum heat dissipation.
• Verify that the input voltage levels match the module's specified operating range (93-132 VAC) to prevent damage.
• Ensure proper grounding of the module chassis to maintain the 1500V isolation integrity.
• Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect internal circuitry.
