Description

The Honeywell 51155506-110 is a specialized relay cable assembly designed for use within the Experion LX control system architecture. This cable assembly serves as a critical interface component for Digital Output (DO) source configurations, facilitating reliable signal transmission between control hardware and field-level relay devices. With a total length of 10.0 meters, it provides the necessary reach for distributed I/O cabinet layouts.

Features

• Designed for Digital Output (DO) source applications.
• 10.0-meter cable length for flexible installation in control cabinets.
• Constructed with 18 AWG conductors for robust signal integrity.
• Rated for 300V AC/DC operation, suitable for standard industrial control voltages.
• High insulation resistance and dielectric strength for enhanced reliability in harsh environments.

Technical Specifications

Installation Guidelines

• Ensure all power is disconnected from the I/O modules and relay boards before connecting or disconnecting the cable assembly.
• Route the cable away from high-voltage power lines and sources of electromagnetic interference (EMI) to prevent signal noise.
• Verify that the connector pins are properly aligned and fully seated to ensure a secure electrical connection.
• Maintain appropriate bend radii during installation to prevent internal conductor fatigue or insulation damage.
• Use cable ties or wire management ducts to secure the cable, ensuring it does not obstruct airflow or access to other system components.

FAQ

What is the primary use of the 51155506-110 cable?
This cable is specifically designed as a relay cable assembly for Digital Output (DO) source applications within the Honeywell Experion LX system.

Can this cable be used in high-temperature environments?
Yes, the cable is rated for operation in temperatures ranging from -40 degC to +85 degC, making it suitable for most industrial control room and cabinet environments.
