Description

The Honeywell 51155506-140 is a high-quality relay cable assembly designed for use within the Experion LX distributed control system architecture. This cable assembly is specifically engineered to facilitate reliable signal transmission for Digital Output (DO) source applications. With a total length of 40 meters, it provides the necessary reach for complex industrial cabinet configurations, ensuring robust connectivity between the control hardware and field termination assemblies.

Features

• Designed for Experion LX system compatibility
• Configured for Digital Output (DO) source signal routing
• Total cable length: 40.0 meters
• Robust construction suitable for industrial environments
• High dielectric strength for electrical safety

Technical Specifications

Installation Guidelines

• Ensure all power is disconnected from the I/O modules and field devices before connecting or disconnecting the cable assembly.
• Route cables through dedicated industrial cable trays to minimize electromagnetic interference (EMI) from high-voltage power lines.
• Avoid sharp bends or excessive tension during installation to maintain the integrity of the internal conductors.
• Verify that the connector pins are clean and free of debris before mating with the corresponding module or terminal block.
• Secure the cable using appropriate strain relief methods to prevent mechanical stress on the connection points.

FAQ

What is the primary function of the 51155506-140 cable?

This cable assembly is used to interface Digital Output (DO) source signals within the Honeywell Experion LX system, providing a reliable physical link between control system modules and field termination points.

Can this cable be used in extreme temperatures?

Yes, the cable is rated for an operating temperature range of -40 degC to +85 degC, making it suitable for most standard industrial control room and plant floor environments.
