Description

The Honeywell 51454416-800 is a high-reliability, fanless cabinet infrastructure chassis designed for use within the Experion LX distributed control system environment. This unit provides a robust, thermally efficient housing for critical control components, ensuring stable operation in demanding industrial conditions without the need for mechanical cooling fans. By utilizing a fanless design, the module reduces maintenance requirements and eliminates potential points of failure associated with moving parts.

Features

• Fanless thermal management design for increased reliability in harsh environments.
• Integrated 200W power supply supporting multiple output rails (+3.3V, +5V, +12V, +24V).
• Advanced thermal monitoring via 6 internal temperature sensors.
• Wide operating temperature range from -30 degC to +65 degC.
• High-voltage isolation rated at 2000V AC.
• Optimized thermal gradient of less than 12 degC across the backplane.

Technical Specifications

Installation Guidelines

• Ensure adequate clearance around the chassis to allow for natural convection cooling, as this is a fanless unit.
• Mount the chassis securely in a standard industrial cabinet, ensuring proper grounding to the cabinet backplane to mitigate EMI.
• Verify input voltage is within the 18-36V DC range before applying power.
• Always power down the system before inserting or removing modules from the chassis backplane to prevent electrical arcing or damage to sensitive components.
• Use shielded cabling for all I/O connections to maintain signal integrity in high-EMI environments.

FAQ

Is this chassis compatible with all Experion LX modules?

The 51454416-800 is designed for specific Experion LX infrastructure applications. Please verify your system hardware manual to ensure compatibility with your specific I/O or controller modules.

Does the fanless design require special cabinet ventilation?

While the unit is designed for fanless operation, it is essential to maintain proper ambient airflow within the cabinet to ensure the internal temperature sensors remain within the specified operating range.
