Description

The Honeywell CC-PWRR01 is a high-reliability redundant power supply system designed for demanding DCS (Distributed Control System) environments. This 20A power system architecture ensures continuous operation by utilizing dual power supply modules, providing the necessary fault tolerance for critical industrial control processes. The system is engineered to handle standard industrial AC inputs and provides a stable DC output with integrated battery backup capabilities.

Features

• Redundant configuration utilizing dual power supply modules for high availability.
• Integrated power adapter boards and rack-mounted TDI power transistors.
• Includes dedicated indication cables for monitoring system status.
• Designed for 120/240 VAC input ranges with wide frequency tolerance.
• Provides 20ms holdup time to maintain output during transient power interruptions.
• Battery backup support for up to 30 minutes at 20A maximum load.

Included Components

• 2x 51202343-001 Indication Cables
• 2x 51199935-100 Power Adapter Boards
• 4x 51198685-100 (SPS5710-2-LF) Power Supply Modules
• 2x 51199930-100 (SPS5713) Rack TDI Power Transistors

Technical Specifications

Installation Guidelines

• Ensure the rack environment is clean and free of conductive debris before installation.
• Verify that the AC input voltage matches the specified 100-230 VAC range.
• Always power down the system before inserting or removing power supply modules or adapter boards.
• Ensure proper grounding of the rack assembly to prevent EMI and protect against surges.
• Maintain adequate clearance around the modules to allow for proper thermal dissipation.
• Connect the provided indication cables securely to monitor the health and redundancy status of the power supply pairs.

FAQ

What is the primary function of the CC-PWRR01?
The CC-PWRR01 serves as a redundant 20A power supply system designed to provide reliable 24VDC power to Honeywell DCS equipment, ensuring uptime through dual-module redundancy.

Does this system include battery backup?
Yes, the system supports battery backup for up to 30 minutes when operating at the maximum 20A load.
