Description

The Honeywell MC-PC1X02 is a high-precision differential pressure transducer designed for demanding industrial process automation environments. This device provides reliable, low-pressure monitoring with a measurement range of +/- 125 psi (+/- 8.62 bar). It is engineered to deliver a stable 4-20 mA analog output, ensuring seamless integration with Distributed Control Systems (DCS), Programmable Logic Controllers (PLC), and SCADA platforms. Designed for longevity and accuracy, the MC-PC1X02 features low annual drift, which minimizes the need for frequent recalibration and helps maintain consistent process control.

Features

• High Precision Sensing: Optimized for stable differential pressure measurement under fluctuating industrial load conditions.
• Analog Output: Standard 4-20 mA current loop signal for noise-resistant, long-distance transmission.
• Robust Construction: Housed in durable Polyphenylene Sulfide (PPS) with an IP66 enclosure rating for protection against moisture, vibration, and corrosive atmospheres.
• Low Drift: Long-term stability rated at +/- 0.1 percent full scale per year.
• Flexible Power: Operates on a wide 12 to 30 VDC supply range with low power consumption.

Applications

The MC-PC1X02 is suitable for a variety of industrial applications, including:

• Refinery process skids
• Boiler and steam management systems
• Gas compression stations
• Water treatment and filtration plants
• HVAC process control and monitoring

Technical Specifications

Installation Guidelines

• Mounting: Ensure the transducer is mounted securely using the provided threaded connections. Avoid high-vibration zones if possible, or use appropriate dampening mounts.
• Wiring: Use shielded twisted-pair cabling for the 4-20 mA loop to prevent electromagnetic interference (EMI) from nearby high-voltage lines or variable frequency drives.
• Sealing: Ensure 1/4 inch NPT process ports are properly sealed using compatible thread sealant to prevent leaks in high-pressure or hazardous media applications.
• Power: Verify that the supply voltage is within the 12-30 VDC range before applying power.
• Handling: As a precision instrument, handle with care to avoid mechanical shock to the sensing diaphragm.

FAQ

What is the primary output signal of the MC-PC1X02?

The transducer provides a standard 4-20 mA analog current loop output, which is ideal for long-distance signal transmission in industrial environments.

What is the IP rating of this device?

The MC-PC1X02 is rated IP66, providing robust protection against dust ingress and powerful water jets, making it suitable for harsh industrial environments.

Can this transducer be used in corrosive atmospheres?

Yes, the housing is constructed from Polyphenylene Sulfide (PPS), which offers excellent chemical resistance, making it suitable for many corrosive industrial settings.
