The GE Fanuc IC200MDL930 is an 8-channel relay output module engineered for the Versamax I/O system. This module provides a versatile interface for switching field devices in industrial automation environments, supporting a wide range of AC and DC voltage levels. Each of the eight output channels is individually isolated, which enhances system reliability by preventing electrical faults from propagating across the control network.

Features

• Eight independent, isolated Form A (Normally Open) relay outputs.
• Supports mixed-voltage applications, including 5 VDC, 24 VDC, 125 VDC, 120 VAC, and 240 VAC control circuits.
• Optical isolation between field-side lines and system logic for superior noise immunity and protection.
• Constructed with high-durability silver alloy contacts for consistent switching performance.
• Integrated diagnostic capability to help minimize downtime in complex control architectures.

Applications

This module is designed for deployment in decentralized I/O configurations, commonly utilized in water management systems, chemical processing facilities, and electrical grid infrastructure where flexible, high-voltage switching is required.

Technical Specifications

Installation Guidelines

• Ensure the system power is disconnected before installing or removing the module from the Versamax carrier.
• Mount the module on a standard DIN rail or panel as specified for the Versamax I/O system.
• Maintain adequate spacing for ventilation to ensure operation within the specified temperature range.
• Use shielded cables for field wiring to minimize EMI in high-noise environments.
• Verify that current loads do not exceed derating specifications when operating above 30 deg C.
• Ensure all field wiring is properly terminated and secured to prevent intermittent contact.

FAQ

Does this module support mixed voltage on the same unit?

Yes, because each of the 8 channels is individually isolated, you can connect different voltages to different channels on the same module, provided you observe the isolation and electrical safety ratings.

What is the maximum switching speed for these relays?

The IC200MDL930 is designed for a maximum switching frequency of 20 cycles per minute. It is not intended for high-speed pulse-width modulation or rapid cycling applications.
