Description

The General Electric IC695RMX128 is a high-performance Redundancy Memory Xchange (RMX) module designed for the PACSystems RX3i control platform. This module facilitates high-speed data synchronization and memory sharing between redundant controller nodes, ensuring seamless failover and data consistency in critical automation applications. It supports complex network configurations and provides robust error detection to maintain system integrity.

Features

• 128 MB SDRAM for high-capacity memory exchange.
• Supports up to 256 nodes per network.
• High-speed 2.12 Gbaud fiber-optic communication via LC connectors.
• Supports hot insertion and removal (hot-swappable) for maintenance without system downtime.
• Configurable network parameters with integrated error detection.
• Compatible with RMC128 and RMX228 modules.

Technical Specifications

Installation Guidelines

• Ensure the RX3i rack is powered down before installing or removing the module, unless the system specifically supports hot-swapping in the current configuration.
• Handle the module by the edges to avoid ESD damage to sensitive electronic components.
• Ensure fiber-optic cables are clean and properly seated in the LC connectors to prevent signal attenuation.
• Maintain proper ventilation within the control cabinet to prevent overheating of the RX3i rack components.
• Verify that the module is fully seated and the locking mechanism is engaged before applying power.

FAQ

What is the primary function of the IC695RMX128?

The IC695RMX128 acts as a memory exchange module that allows redundant RX3i controllers to share memory data at high speeds, which is essential for maintaining synchronized states in high-availability control systems.

Is this module hot-swappable?

Yes, the IC695RMX128 supports hot insertion and removal, allowing for replacement or maintenance without requiring a full system shutdown, provided the rack and software configuration support this feature.

What type of cabling is required for this module?

This module utilizes single-mode fiber-optic cables with LC-type connectors to achieve its high-speed 2.12 Gbaud transmission rate.
