The Schneider Electric TSXP572623 is a high-performance double-format processor module designed for the Modicon Premium automation platform. Engineered for demanding industrial control applications, this processor supports the PL7 Junior and PL7 Pro software environments, offering robust processing capabilities for complex automation tasks.

Features

• Double format module design for Modicon Premium architecture.
• Supports up to 1024 discrete I/O and 80 analog I/O channels.
• Integrated Ethernet TCP/IP (RJ45, 10/100 Mbit/s) and non-isolated serial link (2 x female mini DIN, 19.2 kbit/s) connectivity.
• Transparent Ready concept for seamless network integration.
• Capable of managing 10 to 30 simple process control loops.

Technical Specifications

Installation Guidelines

• Ensure the rack power supply is disconnected before inserting or removing the processor module to prevent electrical damage.
• Verify that the module is correctly seated in the double-slot backplane position and that the locking mechanism is fully engaged.
• Maintain proper ventilation within the control cabinet to ensure the module operates within its specified temperature range.
• Use shielded cables for Ethernet and serial communications to minimize electromagnetic interference (EMI) in high-noise industrial environments.
• Adhere to standard ESD (Electrostatic Discharge) handling procedures when touching the module circuitry.

FAQ

What software is required to program this processor? The TSXP572623 is designed for use with Schneider Electric PL7 Junior or PL7 Pro software.

Does this module support Ethernet connectivity? Yes, it features an integrated Ethernet TCP/IP port via an RJ45 connector, supporting 10/100 Mbit/s communication.

What is the power requirement for this unit? The module consumes 1110 mA at 5 V DC.
