Description

The Siemens 6DS1717-8CC is a specialized calculation module designed for the Teleperm M/ME distributed control system. This module provides binary calculation functionality, serving as a critical component for signal processing and logic execution within the Teleperm automation architecture. It is engineered to handle complex binary operations required for industrial control loops and logic sequences.

Features

• Designed for integration within the Siemens Teleperm M/ME system environment.
• Provides dedicated binary calculation processing capabilities.
• Robust construction suitable for industrial control cabinet mounting.
• Standardized voltage input range for compatibility with existing Teleperm power distribution.

Technical Specifications

Installation Guidelines

• Ensure the system power is completely disconnected before inserting or removing the module from the rack.
• Handle the module using proper ESD (Electrostatic Discharge) protection measures to prevent damage to sensitive internal circuitry.
• Verify that the rack ambient temperature remains within the specified 0 degC to +60 degC range to ensure long-term reliability.
• Ensure proper grounding of the module chassis to the system earth to maintain the 500 V AC isolation integrity.
• Route signal cables away from high-voltage power lines or high-EMI sources to prevent signal interference.

FAQ

What is the primary function of the 6DS1717-8CC?

The 6DS1717-8CC is a binary calculation module used within the Siemens Teleperm M/ME system to perform logic and mathematical operations on binary data signals.

Is this module compatible with other systems?

This module is specifically designed for the Siemens Teleperm M/ME platform. It is not intended for use in general-purpose PLC systems outside of this specific product family.

What are the power requirements for this module?

The module operates on a 24 V DC supply (with an acceptable range of 18–30 V DC) and has a current draw of 200 mA at 5 V.
