Description

The Siemens 6DS1703-8AB is a specialized PC board module designed for the Teleperm industrial control system. This module functions as an MS Point Extension, providing expanded signal handling capabilities for legacy automation environments. Although this component has been discontinued by the manufacturer, it remains a critical spare part for maintaining existing Teleperm installations.

Features

• Compatible with Siemens Teleperm system architectures.
• Provides 14 channels for signal extension and processing.
• Robust PC board design for industrial control applications.
• Direct replacement for existing 6DS1703-8AB hardware.

Applications

This module is primarily utilized in legacy power generation and process automation plants that rely on the Teleperm control platform. It is intended for use in control cabinets where additional point extension capacity is required to support system I/O requirements.

Technical Specifications

Installation Guidelines

• Ensure the control system is powered down before attempting to insert or remove the module from the rack or backplane.
• Handle the PC board by the edges to prevent electrostatic discharge (ESD) damage to sensitive components.
• Verify that the module is correctly seated in the designated slot to ensure proper contact with the system bus.
• Ensure the environment is free from excessive dust, moisture, and high-EMI sources to maintain signal integrity.
• Check that all wiring connections are secure and follow the specific plant documentation for Teleperm I/O mapping.

FAQ

Is this module still manufactured? No, the 6DS1703-8AB has been discontinued by Siemens. We provide refurbished or surplus stock to support legacy systems.

What is the primary function of this board? It serves as an MS Point Extension for the Teleperm system, allowing for the expansion of 14 signal points.
