Description

The Woodward 8406-116 is a high-performance Digital Control Operator Interface Module (OIM) engineered to provide real-time visualization and parameter adjustment for industrial governor systems. Serving as the primary human-machine gateway, this module allows engineers to monitor engine dynamics and turbine states with precision. It is widely utilized in thermal power stations, oil refineries, and large-scale marine propulsion control systems for local system tuning and fault diagnostics.

Features

• Ruggedized industrial display and tactile keypad for high-vibration and EMI-prone environments.
• Dedicated serial communication link for high-speed data refresh rates.
• Multi-level access security to protect critical setpoints from unauthorized modification.
• Optimized low power consumption circuitry.
• High-contrast display visibility suitable for various ambient lighting conditions.

Applications

The 8406-116 is designed for critical control environments, including:

• Power generation and thermal power stations.
• Oil and gas refinery control systems.
• Marine propulsion and engine management.
• Industrial turbine control and monitoring.

Technical Specifications

Installation Guidelines

• Ensure the control system is powered down before installing or removing the module.
• Mount the unit in an enclosure that provides adequate protection against dust and moisture.
• Route communication cables away from high-voltage power lines to minimize EMI interference.
• Verify that the 24 VDC power supply is stable and properly grounded according to site electrical standards.
• Use appropriate ESD precautions when handling the module to prevent damage to internal circuitry.

FAQ

What is the primary function of the Woodward 8406-116?

The 8406-116 serves as an operator interface module for Woodward governor systems, allowing for real-time monitoring, parameter adjustment, and fault diagnostics of turbine or engine control systems.

Can this module be used in marine environments?

Yes, the 8406-116 is designed for rugged industrial use and is commonly deployed in marine propulsion control systems where vibration and environmental durability are required.
