The Woodward CSC3LG120 serves as the primary CSC3 Control Module utilized to execute precise governor control and signal processing across power generation and engine automation platforms.

Hardware Specifications

Actuator Loop Feedback Response and Thermal Dissipation

The Woodward CSC3LG120 processes critical process variable updates to provide real-time actuator loop feedback response within prime mover control systems. Featuring thermal heat sink dissipation profiles optimized for extended thermal ranges, the unit operates from -40 to +85 deg C without performance degradation or signal drift. Operating on a low 5 W power budget at 24 VDC, the internal logic pathways deliver rapid logic execution to maintain tight speed and load regulation under dynamic load steps.

Frequently Asked Questions

Q: What operating voltage and power consumption specs apply to the Woodward CSC3LG120 module?

A: The module operates on a standard 24 VDC supply voltage with a low power consumption rating of 5 W.

Q: What environmental temperature range can the CSC3LG120 withstand during operation?

A: The module is engineered to operate reliably in severe thermal conditions ranging from -40 to +85 deg C.

Q: What are the physical chassis dimensions and total weight for cabinet space allocation?

A: The enclosure measures 120 mm x 100 mm x 60 mm and has an overall mass of 1.2 kg.

Field Installation Guidelines

• Mount the module inside an IP54-rated or better enclosure to shield internal electronics from ambient industrial contaminants.
• Connect the 24 VDC auxiliary power supply through dedicated terminal blocks, ensuring an external fast-acting fuse rated for the branch circuit is in place.
• Use shielded cable runs for all signal I/O to minimize electromagnetic noise pickup from nearby heavy electrical equipment.
• Ensure single-point grounding of all cable shields at the enclosure entry point to prevent ground loop currents from interfering with control loops.
