Configured for precise power regulation and fuel metering in gas turbine control architectures, the Woodward CSC3SUWA (CSC3 Power Controller) provides direct physical/electrical execution. This specialized module interfaces directly with governor loops to balance energy outputs across simple-cycle and combined-cycle turbine platforms.

Hardware Specifications

Actuator Loop Feedback Response and Thermal Dissipation

The Woodward CSC3SUWA utilizes dynamic closed-loop processing to deliver high-speed actuator loop feedback response during rapid grid load transitions. Featuring custom thermal heat sink dissipation profiles integrated directly into the chassis, the controller maintains consistent voltage regulation and minimal signal drift up to +70 deg C. Onboard Ethernet and Modbus interfaces ensure real-time telemetry transfer and synchronized command delivery across distributed turbine control nodes.

Frequently Asked Questions

Q: What power input voltage is required for the Woodward CSC3SUWA controller?

A: The module operates from a standard 24 VDC auxiliary power supply source.

Q: What communication protocols are supported by the unit for system integration?

A: The controller features onboard hardware interfaces supporting both Ethernet network connectivity and Modbus serial communications.

Q: What physical installation options are available for mounting this unit in a control cabinet?

A: The chassis measures 30 cm x 20 cm x 25 cm and supports either panel-mount or rack-mount installation configurations.

Field Installation Guidelines

• Secure the 10 kg controller using all designated mounting holes when panel or rack mounting to prevent mechanical stress under high vibration.
• Route incoming 24 VDC auxiliary power wires through an external protective fuse block, observing correct terminal polarity.
• Use shielded Ethernet and twisted-pair Modbus cabling, grounding all shield conductors at a single cabinet point to prevent electrical noise coupling.
• Maintain at least 50 mm of vertical clearance above and below the chassis to allow free airflow across the passive heat sink structures.
