Bently Nevada 3300/48-01-01-00-00 Case Expansion Monitor Module

Bently Nevada 3300/48-01-01-00-00 Case Expansion Monitor Module

The Bently Nevada 3300/48 Case Expansion Monitor is a specialized rack-mounted module engineered to track the thermal growth of turbine casings in relation to the machine foundation. By monitoring this...

22 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 1

SKU: 3300/48-01-01-00-00
Proveedora: Bently Nevada
tipo: Case Expansion Monitor Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Bently Nevada 3300/48 Case Expansion Monitor is a specialized rack-mounted module engineered to track the thermal growth of turbine casings in relation to the machine foundation. By monitoring this expansion, the system prevents mechanical interference, which is vital for the integrity of large rotating machinery, including steam turbines. This module performs continuous signal processing and provides real-time comparisons against user-configured alarm setpoints, facilitating proactive maintenance and operational safety.

Features

  • Designed for precise monitoring of casing expansion using proximity probes or LVDT inputs.
  • Provides integrated Alert and Danger alarm logic for machinery protection.
  • Features front-panel LED status indicators for OK, Bypass, Alert, and Danger states.
  • Standard relay outputs for direct integration into plant protection systems.
  • Compatible with the Bently Nevada 3300 series rack architecture.

Applications

This module is primarily deployed in power generation and heavy industrial facilities where large-scale rotating equipment requires thermal growth monitoring. It is essential for protecting turbines and compressors during startup, shutdown, and steady-state operation.

Technical Specifications

Model 3300/48-01-01-00-00
Brand Bently Nevada
Series 3300
Operating Temperature 0 to 60 deg C
Power Consumption 1.5 W (typical)
Input Compatibility Proximity probes or LVDTs
Signal Accuracy ±0.33% (typ), ±1% (max) at 25 deg C
Output Signals 4 to 20 mA, 1 to 5 VDC, 0 to -10 VDC

Installation Guidelines

  • Ensure the 3300 rack is powered down before inserting or removing any module to prevent electrical damage.
  • Verify that the module is properly seated in the rack slot to ensure backplane connectivity.
  • Maintain proper ventilation in the cabinet to keep ambient temperatures within the 0 to 60 deg C range.
  • Use shielded cabling for all transducer inputs to minimize electromagnetic interference (EMI).
  • Follow standard ESD (Electrostatic Discharge) handling procedures when touching internal components.

FAQ

Does this module support custom alarm setpoints?

Yes, the 3300/48 monitor allows for configurable alarm setpoints for both Alert and Danger levels, which are processed based on the input signal from your displacement transducers.

What is the primary input type for this model?

The 3300/48-01-01-00-00 is configured for compatibility with standard proximity probes or LVDT sensors, ensuring accurate measurement of linear expansion.
