ABB RINT-5521C 3AUA0000016016E Inverter Power Driver Board

ABB RINT-5521C 3AUA0000016016E Inverter Power Driver Board

The ABB RINT-5521C (3AUA0000016016E) is a high-performance Main Circuit Interface and IGBT Gate Driver board engineered for the ABB ACS800 series variable frequency drives. This module is essential for managing...

29 la gente está viendo esto ahora mismo

Disponibilidad: En existencias

SKU: RINT-5521C 3AUA0000016016E
Proveedora: ABB
tipo: Inverter Power Driver Board
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The ABB RINT-5521C (3AUA0000016016E) is a high-performance Main Circuit Interface and IGBT Gate Driver board engineered for the ABB ACS800 series variable frequency drives. This module is essential for managing power switching in industrial inverter systems, typically supporting units within the 55 kW to 75 kW power range.

Features

  • Designed specifically for ABB ACS800 series drive architecture.
  • Functions as a critical IGBT Gate Driver Interface Board.
  • Supports Safe Torque Off (STO) functionality, meeting SIL 3 safety standards.
  • Provides galvanic isolation for I/O signals to protect control logic from high-power circuit transients.
  • Includes advanced thermal monitoring for IGBT junction and heat sink temperature management.
  • Supports motor thermal protection estimation based on real-time load data.

Applications

  • Power Generation: Control of pumps, fans, and auxiliary rotating equipment in power plants.
  • Oil & Gas: Management of large motor drives in pumping stations, drilling platforms, and pipelines.
  • Metallurgy & Mining: Startup and operational monitoring for heavy-duty industrial machinery.
  • Chemical Processing: Precise speed and torque control for critical rotating equipment.

Technical Specifications

Model RINT-5521C
Order Code 3AUA0000016016E
Manufacturer ABB
Control Voltage +24 V dc
Gate Drive Output ±15 V typical
Switching Frequency Up to 4 kHz
Power Consumption 15-25 W
Operating Temperature -40 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Humidity 5-95% RH (non-condensing)

Installation Guidelines

  • Power Down: Always disconnect all power sources from the drive before attempting to install or remove the RINT-5521C board.
  • ESD Protection: Use an anti-static wrist strap and grounded work surface to prevent electrostatic discharge damage to sensitive electronic components.
  • Configuration: Note that this board may require specific configuration (such as soldering jumpers) to match the current scaling for phases U, V, and W based on the specific inverter frame size.
  • Seating: Ensure the board is firmly seated in the designated drive slot and all ribbon cables or connectors are fully engaged and locked.
  • Environment: Ensure the drive cabinet provides adequate ventilation to maintain operating temperatures within the specified range.

FAQ

What is the primary function of the RINT-5521C?

The RINT-5521C acts as the main circuit interface and gate driver board for the ACS800 drive, facilitating the switching of IGBTs and providing essential safety and thermal monitoring signals.

Which drive models are compatible with this board?

This board is compatible with various ABB ACS800 series units, including the ACS800-01, ACS800-04, and ACS800-11 models within the 55 kW to 75 kW range.

Does this board support safety features?

Yes, it supports the Safe Torque Off (STO) function, which is designed to prevent the motor from generating torque, adhering to SIL 3 safety requirements.
