Allen-Bradley 1746SC-INO4I Individually Isolated Analog Output Module

Allen-Bradley 1746SC-INO4I Individually Isolated Analog Output Module

Description

The 1746SC-INO4I is a high-performance, four-channel analog output module engineered by Spectrum Controls for the Allen-Bradley SLC 500 platform. This module is specifically designed for current-only applications (0-20 mA or...

22 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 5

SKU: 1746SC-INO4I
Proveedora: Allen-Bradley
tipo: Analog Output Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The 1746SC-INO4I is a high-performance, four-channel analog output module engineered by Spectrum Controls for the Allen-Bradley SLC 500 platform. This module is specifically designed for current-only applications (0-20 mA or 4-20 mA) where electrical noise, ground loops, or differing potentials between field devices could compromise signal accuracy. The 'I' designation confirms individual channel-to-channel isolation, ensuring that a fault or noise on one loop does not propagate to other outputs or the backplane.
