Allen-Bradley 2711P-B7C15A2 PanelView Plus 700 HMI Terminal

Allen-Bradley 2711P-B7C15A2 PanelView Plus 700 HMI Terminal

The Allen-Bradley 2711P-B7C15A2 is a high-performance operator terminal from the PanelView Plus 700 series, engineered for robust visualization and control in demanding industrial environments. This HMI unit features a 6.5-inch...

21 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 10

SKU: 2711P-B7C15A2
Proveedora: Allen-Bradley
tipo: HMI Terminal
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Allen-Bradley 2711P-B7C15A2 is a high-performance operator terminal from the PanelView Plus 700 series, engineered for robust visualization and control in demanding industrial environments. This HMI unit features a 6.5-inch active-matrix color TFT display, providing clear operational data through a 640 x 480 pixel resolution. Designed for reliability, the terminal integrates both a 22-key stainless steel membrane keypad and an analog resistive touchscreen, offering flexible input options for operators in continuous processing, power generation, and manufacturing sectors.

Features

  • 6.5-inch color TFT display with 300 cd/m2 brightness for high visibility.
  • Dual-input interface: 22-key keypad and analog resistive touchscreen.
  • Integrated ControlNet communication module for reliable backplane connectivity.
  • 128 MB RAM and 128 MB non-volatile storage for FactoryTalk View ME applications.
  • Rugged NEMA 12/13 rated enclosure for protection against dust and non-corrosive liquids.
  • Long-life LED backlight rated for 50,000 hours of operation.

Applications

This terminal is suitable for complex industrial automation tasks, including real-time monitoring of production lines, alarm management, and parameter logging. Its ControlNet interface makes it ideal for high-speed communication within Allen-Bradley controller networks in refineries, utility plants, and automated assembly lines.

Technical Specifications

Model 2711P-B7C15A2
Display 6.5-inch Color TFT LCD
Resolution 640 x 480 pixels
Input Voltage 85 to 264 VAC (47-63 Hz)
Power Consumption 160 VA max
Communication ControlNet
Memory 128 MB RAM / 128 MB Flash
Operating Temperature 0 to 55 deg C
Storage Temperature -25 to 70 deg C
Enclosure Rating NEMA 12, 13

Installation Guidelines

  • Ensure the panel cutout is prepared according to the manufacturer's mounting template to maintain the NEMA seal.
  • Verify that the supply voltage is within the 85-264 VAC range before applying power.
  • Use shielded communication cables for the ControlNet interface to minimize EMI interference.
  • Maintain adequate clearance around the unit to ensure proper ventilation and prevent overheating.
  • Always power down the terminal before performing maintenance or replacing the backlight module (2711P-RL7C).
  • Handle the touchscreen with care; avoid using sharp objects that may damage the resistive overlay.

FAQ

What is the primary communication protocol for this HMI?

The 2711P-B7C15A2 is equipped with a dedicated ControlNet communication module for high-speed data exchange with compatible Allen-Bradley controllers.

Can this unit be used in dusty environments?

Yes, the terminal is rated for NEMA 12 and 13, making it suitable for indoor industrial environments where protection against dust, lint, and dripping non-corrosive liquids is required.
