Allen-Bradley 2711P-K10C6D7 PanelView Plus 1000 HMI Operator Terminal

Allen-Bradley 2711P-K10C6D7 PanelView Plus 1000 HMI Operator Terminal

The Allen-Bradley 2711P-K10C6D7 is a high-performance HMI operator terminal designed for robust machine visualization and process control in demanding industrial sectors, including power generation, chemical processing, and mining. This unit...

23 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 9

SKU: 2711P-K10C6D7
Proveedora: Allen-Bradley
tipo: HMI Operator Terminal
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Allen-Bradley 2711P-K10C6D7 is a high-performance HMI operator terminal designed for robust machine visualization and process control in demanding industrial sectors, including power generation, chemical processing, and mining. This unit features a 10.4-inch active-matrix color TFT display and a durable membrane keypad, providing operators with clear visual feedback and reliable input capabilities in challenging environments.

Features

  • 10.4-inch active-matrix color TFT display for high-resolution process monitoring.
  • Tactile membrane keypad designed for reliable operation in industrial settings.
  • Integrated Data Highway Plus (DH+) and DH-485 communication ports for seamless multi-node network integration.
  • USB and PC memory card interfaces for efficient firmware updates, data logging, and parameter management.
  • Rugged DC power architecture (18-32 VDC) for stable operation under varying electrical conditions.

Applications

This terminal is engineered for integration into complex automation systems where direct PLC data mapping is required. It is suitable for control rooms and local machine-level interfaces, helping to minimize downtime through enhanced diagnostic visibility and simplified control logic.

Technical Specifications

Model 2711P-K10C6D7
Display Size 10.4 in.
Display Type Active-Matrix Color TFT
Input Method Membrane Keypad
Operating Voltage 18-32 VDC
Internal Memory 128 MB
Operating Temperature 0 to 55 deg C
Storage Temperature -25 to 70 deg C
Humidity 5-95 percent non-condensing
Replacement Backlight 2711P-RL10C

Installation Guidelines

  • Ensure the unit is mounted in a panel with adequate ventilation to maintain operating temperatures within the 0-55 deg C range.
  • Use shielded communication cables (e.g., 1770-CD or 1761-CBL-ASO3) to minimize EMI interference in high-noise industrial environments.
  • Verify that the DC power supply is within the 18-32 VDC range before connection to prevent damage to internal circuitry.
  • Always power down the system before inserting or removing memory cards or communication modules.
  • Handle with care to avoid damage to the membrane keypad and display surface; ensure the gasket is properly seated to maintain the NEMA/IP rating of the enclosure.

FAQ

What communication protocols are supported by the 2711P-K10C6D7?
This model supports Data Highway Plus (DH+) and DH-485, allowing for direct connectivity to compatible Allen-Bradley PLC controllers.

Is the backlight replaceable on this unit?
Yes, the backlight is field-replaceable using the 2711P-RL10C replacement part.
