Allen-Bradley 2711P-K15C15D1 PanelView Plus 1500 Operator Terminal

Allen-Bradley 2711P-K15C15D1 PanelView Plus 1500 Operator Terminal

The Allen-Bradley 2711P-K15C15D1 is a high-performance industrial operator interface terminal from the PanelView Plus 1500 series. Engineered for demanding environments such as power generation, heavy manufacturing, and water treatment, this...

17 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 2

SKU: 2711P-K15C15D1
Proveedora: Allen-Bradley
tipo: Operator Interface Terminal
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Allen-Bradley 2711P-K15C15D1 is a high-performance industrial operator interface terminal from the PanelView Plus 1500 series. Engineered for demanding environments such as power generation, heavy manufacturing, and water treatment, this terminal provides reliable real-time process monitoring and control. It features a 15-inch active-matrix TFT color display with a resolution of 1024 x 768, ensuring clear visualization of complex machine analytics and system status.

Features

  • Rugged Input Interface: Equipped with a durable stainless-steel dome membrane keypad designed for consistent tactile feedback and long-term reliability in high-vibration control rooms.
  • Display Technology: High-visibility 15-inch TFT display with a brightness of 300 cd/m2, optimized for readability in varied ambient lighting conditions.
  • Memory Architecture: Includes 64 MB of system RAM and 64 MB of non-volatile flash memory for stable application execution, alarm logging, and data retention.
  • Vibration Resistance: Chassis construction rated for continuous operation under mechanical stress up to 2G at frequencies between 57 Hz and 500 Hz.
  • Backlight System: Features a field-replaceable CCFL backlight assembly with an expected service life of 50,000 hours.

Technical Specifications

Model 2711P-K15C15D1
Display Size 15 inches
Display Type Color Active Matrix TFT
Resolution 1024 x 768 (18-bit)
Input Voltage 18 to 32 VDC (24 VDC nominal)
Operating Temperature 0 to 55 deg C
Storage Temperature -25 to 70 deg C
System RAM 64 MB
Flash Memory 64 MB

Installation Guidelines

  • Mounting: Ensure the unit is mounted in a panel with adequate clearance for ventilation to prevent overheating. Use the provided mounting clips to secure the bezel against the enclosure gasket for an IP-rated seal.
  • Power Wiring: Connect to a 24 VDC power source within the 18-32 VDC range. Ensure proper grounding of the chassis to a common earth ground point to mitigate EMI.
  • ESD Precautions: Always handle the unit with static-safe practices. Avoid touching internal components or exposed connector pins.
  • Maintenance: Power down the terminal before performing any maintenance, including the replacement of the CCFL backlight or cleaning of the membrane keypad.

FAQ

Q: What is the primary input method for this terminal?
A: This model utilizes a stainless-steel dome membrane keypad, which provides tactile feedback suitable for industrial environments.

Q: Can the backlight be replaced in the field?
A: Yes, the unit is designed with a field-replaceable CCFL backlight assembly to extend the operational life of the display.

Q: Is this terminal suitable for high-vibration applications?
A: Yes, the 2711P-K15C15D1 is rated to withstand continuous vibration up to 2G at frequencies between 57 Hz and 500 Hz.
