Allen-Bradley 2711P-K15C15D2 PanelView Plus 1500 Interface Terminal

Allen-Bradley 2711P-K15C15D2 PanelView Plus 1500 Interface Terminal

The Allen-Bradley 2711P-K15C15D2 is a high-performance industrial graphic terminal from the PanelView Plus 1500 series, engineered for reliable visualization and machine control in demanding manufacturing environments. This unit provides operators...

22 la gente está viendo esto ahora mismo

Disponibilidad: En existencias

SKU: 2711P-K15C15D2
Proveedora: Allen-Bradley
tipo: Interface Terminal
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Allen-Bradley 2711P-K15C15D2 is a high-performance industrial graphic terminal from the PanelView Plus 1500 series, engineered for reliable visualization and machine control in demanding manufacturing environments. This unit provides operators with a clear, 15-inch active-matrix color display, ensuring precise monitoring of process variables, alarms, and complex graphical schematics.

Features

  • High-Resolution Display: 15-inch color active-matrix screen with 1024 x 768 pixel resolution for detailed process visualization.
  • Tactile Input: Integrated stainless-steel dome keypad featuring dedicated numeric and directional keys, designed for high-frequency use and durability in industrial settings.
  • Robust Connectivity: Equipped with integrated Ethernet for network communication, RS-232 serial ports for legacy device support, and USB host ports for peripheral expansion and data management.
  • High-Capacity Memory: Features 128 MB of system memory to support extensive tag databases, trending logs, and efficient screen navigation.

Applications

This interface terminal is suitable for a wide range of automation tasks, including:

  • Automotive assembly line monitoring and control.
  • Chemical processing plant visualization.
  • Material handling and logistics systems.
  • Supervisory control and data acquisition (SCADA) interface nodes.

Technical Specifications

Model 2711P-K15C15D2
Series PanelView Plus 1500
Display Size 15 inches
Resolution 1024 x 768 pixels
Input Voltage 24 VDC (18-32 VDC range)
Memory 128 MB
Communication Ethernet, RS-232, USB
Operating Temperature 0 to 55 deg C
Storage Temperature -25 to 70 deg C
Humidity 5 to 95 percent non-condensing

Installation Guidelines

  • Ensure the terminal is mounted in a NEMA/IP-rated enclosure suitable for the plant environment to protect against dust and moisture.
  • Verify that the power supply provides a stable 24 VDC nominal input within the specified 18-32 VDC range.
  • Maintain adequate clearance around the unit to ensure proper ventilation and prevent overheating.
  • Use shielded communication cables for Ethernet and RS-232 connections to minimize electromagnetic interference (EMI) in high-noise environments.
  • Always disconnect power before performing any wiring, maintenance, or module replacement to prevent electrical hazards.

FAQ

What is the primary input method for this terminal?

This model features a tactile stainless-steel dome keypad, which includes both numeric and directional navigation keys for precise operator input.

Can this terminal be connected to a local network?

Yes, the unit includes an integrated Ethernet port, allowing it to communicate with programmable automation controllers and other supervisory systems over standard factory networks.
