Bently Nevada 330104-00-06-05-01-05 3300 XL 8 mm Proximity Probe

Bently Nevada 330104-00-06-05-01-05 3300 XL 8 mm Proximity Probe

The Bently Nevada 330104-00-06-05-01-05 is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and shaft displacement measurements in critical rotating machinery. As a core component of...

20 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 8

SKU: 330104-00-06-05-01-05
Proveedora: Bently Nevada
tipo: Proximity Probe
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The Bently Nevada 330104-00-06-05-01-05 is a high-performance 3300 XL 8 mm proximity probe designed for precise vibration and shaft displacement measurements in critical rotating machinery. As a core component of the Bently Nevada eddy current transducer system, this probe provides accurate, non-contact monitoring of both static position and dynamic vibration, making it essential for turbines, compressors, and fluid-film bearing machines.

Features

  • Advanced Construction: Features a patented TipLoc molding method for a robust bond between the probe tip and body, and a CableLoc design providing 330N (75 lbf) pull strength.
  • Material: Probe tip is constructed from Polyphenylene Sulfide (PPS) for enhanced chemical resistance.
  • Interchangeability: Fully compatible with other 3300-series 5 mm and 8 mm components.
  • Hazardous Area Ready: Includes CSA, ATEX, and IECEx agency approvals for safe operation in demanding environments.
  • Configuration: Equipped with a miniature coaxial ClickLoc connector and connector protector.

Applications

  • Vibration and position monitoring on fluid-film bearing machines.
  • Keyphasor reference and speed measurement.
  • Critical asset protection in power generation, petrochemical, and mining facilities.
  • Monitoring of cooling tower fans, agitators, and large-scale ventilation systems.

Technical Specifications

Model 330104-00-06-05-01-05
Probe Diameter 8 mm
Thread Size M10 x 1
Unthreaded Length 0 mm
Case Length 60 mm
Cable Length 0.5 meter (1.6 feet)
Connector Type Miniature coaxial ClickLoc with protector
Approvals CSA, ATEX, IECEx
Default Calibration AISI 4140 Steel

Installation Guidelines

  • Handling: Ensure the probe tip is protected from physical impact during installation. Use caution when routing the coaxial cable to avoid sharp bends that exceed the minimum bend radius.
  • Mounting: The probe is designed for mounting into a threaded hole. Ensure the probe is secured firmly to prevent mechanical resonance.
  • Grounding: The probe system is designed to be electrically isolated from the machine case, reducing the risk of ground loops.
  • Environment: While the probe is robust, it should be installed in a manner that protects the connector from direct exposure to process fluids and extreme contaminants.
  • Safety: Always power down the monitoring system before connecting or disconnecting the probe cable to prevent electrical transients.

FAQs

What is the primary function of this probe?

This probe is an eddy current transducer that measures the distance between the probe tip and a conductive target, allowing for the monitoring of shaft vibration and position in rotating equipment.

Can this probe be used in hazardous areas?

Yes, this specific model (suffix -05) carries CSA, ATEX, and IECEx approvals, making it suitable for use in designated hazardous locations when installed according to local safety codes.

Is the probe compatible with non-XL 3300 systems?

Yes, it is physically and electrically interchangeable with other 3300-series 5 mm and 8 mm probes. Note that mixing XL and non-XL components will limit the overall system performance to the non-XL specification.
